Amplifier Built-In Sensors

High quality photoelectric sensors with built-in amplifiers

Z4 Series

These IO-Link sensors consists of the 4 different sensor types such as through beam(25m), retro reflective (0.01-4m), diffuse reflective (0-1m) and also limited diffuse reflective systems(10-90mm). It has a 4-element LED light source with a wavelength of 632nm. Sensitivity can be adjusted with a 1 turn potentiometer or via IO-Link network.

Z-M Series

This series of sensors has excellent oil and water resistance which comes in cable and a connector type. For its cable type, it has a degree of protection of IP69K which is equivalent to IP67g connector type. It has a low deterioration 4 element LED light source and a 1 turn potentiometer for distance adjustment.

C-R Series

These cylindrical sensors with a maximum sensing distance of 25m have a full-metal housing in brass which are also easy to align. The structure is made from hotmelt molding that has high vibration resistance and is watertight (IP67). It has a red LED light source and a 1-turn potentiometer for sensitivity adjustment.

V Series

These series of sensors have a 2 directional terminal block system useful for installation that can be connected downwards and rearwards. They are equipped with a timer function as well as a mirror surface detection system. A 1-turn potentiometer (240 degree angle) is available for distance adjustment.

Z3 Series

Similar to the Z4 series, this series have 2 extra optical system types which is the wide angle diffuse reflective and transparent object detection which uses the retro reflective system. Furthermore, it has a maximum sensing distance of 25m and it shares the same light source and wavelength as the Z4 series which only includes a 1-turn potentiometer for distance adjustment

E Series

These miniature sensors has flexible mounting holes as well as visible indicators from the back of the housing (Flat ON type) systems. Side ON types are also available. These sensors also features angled cable design so that they can be mounted in various positions without stress on the cable as well as a mounting hole pitch of 8-11mm. It also has a red LED light source.

C2 Series

These cylindrical sensors has a selectable plastic and metal enclosure which has a rich lineup of 100 variations. It has a custom ASIC with power circuit to help avoid defects by electrical damage from the power line. Furthermore, is also has a max hysteresis of 10% between white and black colours . A 1- turn potentiometer is also available for distance adjustment.

Z2 Series

These cost effective and eco friendly sensors only consists of the through beam, diffuse reflective and the retro reflective type systems. Similarly, they also have a maximum sensing distance of 25m and have a 4 element red LED light source with a wavelength of 640nm and a 1 turn potentiometer to adjust distance setting. There are also easy-to-see indicators and operating panel so as to allow labelling to be seen easily in the dark.

J Series

These water/oil resistant sensors has a vibration resistance far above of the JIS standards. Furthermore, they also include mounting holes from 10mm to 25.4 mm as well a Head ON type and a Side ON type. Aside from the through beam type, these series have a red LED light source with a 2-turn endless potentiometer with indicator for distance adjustment.

V3/V4 Series

These universal voltage sensors allows selections of connection types with a high sensing distance of 70m. These sensors also come in DC power type which includes a cable, connector and a terminal block type whereas the universal voltage only have terminal block and cable type. It also has a 1-turn potentiometer for distance adjustment.

ZR-X Series

This coaxial retro reflective system sensor has a sensing distance of 0-2.5m with a red LED light source and is able to eliminate detection dead areas between a reflector. The sensitivity can be adjusted using a 1-turn volume system and it also has a fast response of 250μs.

S Series

These small photoelectric sensors can be installed anywhere which has a high speed response time of 0.5ms which is very suitable for high speed production lines. It has a red LED light source with a 1-turn potentiometer for distance adjustment and a shock resistance up to 100G.

V2 Series

Similar to the V3/V4 series, this renewed V2 series comes with high-level specifications which also have both universal voltage and DC power types. Both DC and universal types have a red LED light source as well as 2 - turn endless potentiometer with indicator for distance adjustments.
